Internet of Things

Our IoT designs use espressif ESP8266EX chip. ESP8266EX is very highly integrated SoC which includes Tensilica's L106 32-bit core processor; SRAM; power management unit; RF front end. ESP8266EX has a number of interfaces - I2C, SPI, SDIO and also a number of free GPIO pins. The chip allows the implementation of a WIFI TCP-IP stack with just few extra components beside the ESP8266EX.

CHIP FEATURES:

  • Complies with 802.11 b/g/n
  • Integrated low power 32-bit MCU
  • Integrated 10-bit ADC
  • Integrated TCP/IP protocol stack
  • Integrated TR switch, balun, LNA, power amplifier and matching network
  • Integrated PLL, regulators, and power management units
  • Supports antenna diversity
  • WiFi 2.4 GHz, support WPA/WPA2
  • Support STA/AP/STA+AP operation modes
  • Support Smart Link Function for both Android and iOS devices
  • SDIO 2.0, (H) SPI, UART, I2C, I2S, IR Remote Control, PWM, GPIO
  • STBC, 1x1 MIMO, 2x1 MIMO
  • A-MPDU & A-MSDU aggregation & 0.4s guard interval
  • Deep sleep power <10uA, Power down leakage current < 5uA
  • Wake up and transmit packets in < 2ms
  • Standby power consumption of < 1.0mW (DTIM3)
  • +20 dBm output power in 802.11b mode
  • Operating temperature range -40C ~ 125C
  • FCC, CE, TELEC, WiFi Alliance, and SRRC certified
Price44.00 EUR
Out of stock
Price17.00 EUR
10 - 49 pcs15.30 EUR
50 - 10000 pcs13.60 EUR
Price6.00 EUR
10 - 49 pcs5.40 EUR
50 - 10000 pcs4.80 EUR

Price5.00 EUR
10 - 49 pcs4.50 EUR
50 - 10000 pcs4.00 EUR

Price5.50 EUR
10 - 49 pcs4.95 EUR
50 - 10000 pcs4.40 EUR

Price9.95 EUR
10 - 49 pcs8.96 EUR
50 - 10000 pcs7.96 EUR

Price12.95 EUR
10 - 49 pcs11.66 EUR
50 - 10000 pcs10.36 EUR

Price19.95 EUR
10 - 49 pcs17.96 EUR
50 - 10000 pcs15.96 EUR
