ESP32-DevKit-LiPo

ESP32-DevKit-LiPo - Open Source Hardware Board
ESP32-DevKit-LiPo - Open Source Hardware Board ESP32-DevKit-LiPo - Open Source Hardware Board
ESP32 WiFi/BLE Development board

Select Product Variant

  • ESP32-DevKit-Lipo
  • ESP32-DevKit-Lipo-EA
  • ESP32-WROVER-DevKit-Lipo
Price7.45 EUR
10 - 49 pcs7.08 EUR
50 - 10000 pcs6.71 EUR
In Stock
ESP32-DevKit-LiPo is OSHW certified Open Source Hardware with UID BG000019

This board is pin to pin compatible with Espressif ESP32-CoreBoard (ESP32-DevKitC), but adds Lipo charger and ability to work on LiPo power when external power supply is missing, allowing handheld applications.
All components used are with industrial grade oprating temperature -40+85C.

ESP32-DevKit-Lipo-EA comes with ESP32 module with U.FL connector and external antenna attached.

ESP32-WROVER-DevKit-Lipo comes with ESP32-WROVER module with 4MB flash and 8MB PSRAM. Power consumption of ESP32-WROVER-DevKit-Lipo is 65 uA in deep sleep mode.

FEATURES

  • ESP32-WROOM-32 WiFi/BLE module or ESP32-WROVER module
  • User button
  • Micro USB connector
  • Built-in USB-Serial programmer
  • Built-in LiPo charger
  • LiPo battery connector
  • PCB dimensions: (1.9 x 1.1)" ~ (4.8 x 2.8)cm
  • Operating temperature -40+85C
