STR-H711

STR-H711
Header board for STR711 ARM7TDMI-S microcontroller
Price32.95 EUR
10 - 49 pcs29.66 EUR
50 - 10000 pcs26.36 EUR
In stock

FEATURES

  • MCU: STR711FR2T6 16/32 bit ARM7TDMI™ with 256K Bytes Program Flash, 64K Bytes RAM, USB 2.0, RTC, 12 bit ADC, 4x UARTs, 2x I2C,2x SPI, 5x 32bit TIMERS, 2x PWM, 2x CCR, WDT, up to 50MHz operation
  • Standard JTAG connector with ARM 2x10 pin layout for programming/debugging with ARM-JTAG
  • Perfect solution for developing USB peripherials
  • USB connector
  • RESET circuit
  • RESET button
  • Status LED
  • Power supply LED
  • On board voltage regulator 3.3V with up to 800mA current
    single power supply: takes power from USB port or extension connector pin
  • 4 Mhz crystal oscillator
  • 32768 Hz crystal and RTC backup battery connector
  • Extension headers for all uC ports
  • PCB: FR-4, 1.5 mm (0,062"), soldermask, silkscreen component print
  • Dimensions: 50 x 34mm (2 x 1.3")
  • Distance between the exntension connectors: 25.4 mm (1")

SOFTWARE

  • Blinking LED
  • Sample mouse driver with STR711
  • UART routines
  • SD/MMC read/write routines
  • button read, potentiometer ADC read
  • OpenOCD + Eclipse set of projects 1.00 include flash write make file for STR-H711. The complete list of projects included is here.
