MOD-USB-RS232

MOD-USB-RS232 - Open Source Hardware Board
MOD-USB-RS232 - Open Source Hardware Board MOD-USB-RS232 - Open Source Hardware Board
USB to RS232 converter
Price10.95 EUR
10 - 49 pcs9.86 EUR
50 - 10000 pcs8.76 EUR
In stock

FEATURES

  • MCU: PIC18F14K50-I/SS 20-Pin USB Flash Microcontrollers with nanoWatt XLP Technology.
  • Mini USB connector
  • Status LED
  • Male UEXT connector plus 10 pin cable for it
  • RESET circuit
  • FR-4, 1.5 mm, red soldermask, component print
  • -40+85C operating temperature
  • Dimensions: 35.70 x 25.83 mm (1.41 x 1.02")

SOFTWARE

FAQ

  • I want to power the board connected at the UEXT using the MOD-USB-RS232. What should I do?
  • Close jumper UEXT_PWR_3.3. Make sure that the other board does NOT provide power on the UEXT. If both boards provide power via the UEXT connector, a short-circuit would occur.
