STR730-STK

STR730-STK
Development board for STR730 ARM7TDMI-S microcontroller
Price79.95 EUR
10 - 49 pcs71.96 EUR
50 - 10000 pcs63.96 EUR
In stock

FEATURES

  • MCU: STR730
  • Standard JTAG connector with ARM 2x10 pin layout for programming/debugging with ARM-JTAG
  • 3x CAN drivers and connectors
  • 2x RS232 interface and drivers
  • 4x optoisolated inputs
  • 2 RELAYS 10A/250VAC
  • 4x Buttons
  • Trimmer potentiometer
  • LCD display 16x2 with backlight
  • 2 x UEXT - 10 pin extension connector for Olimex addon peripherials like MP3, RF2.4Ghz, RFID etc. modules
  • MOTOR PWM extension connector
  • ANALOGUE extension connector
  • On board voltage regulator 5V with up to 800mA current
  • Single power supply: 12VDC required
  • Power supply LED
  • Power supply filtering capacitor
  • RESET circuit
  • RESET button
  • 4 Mhz crystal
  • PCB: FR-4, 1.5 mm (0,062"), soldermask, silkscreen component print
  • Dimensions: 170 x 115 mm (6.7 x 4.5")
