Header board in DIL40 format for ADuC7020 ARM7 microcontroller
Price33.95 EUR
10 - 49 pcs30.56 EUR
50 - 10000 pcs27.16 EUR
In stock

ADuC-H7020 provides a low-cost way to develop with the ADuC7020 microcontroller without the need of fancy soldering skils. This board is designed to fit in a normal DIL40 socket, so you can make your prototypes easy and troubles free. ADuC7020 is unique with the 1Msps ADCs and DACs and with the 3 phase PWM.

FEATURES

  • MCU: ADuC7020 - ARM7TDMI Core, 16/32-bit RISC architecture, 5 Channels 12-bit, 1MSPS ADC, Differential and single-ended modes, 0 to Vref Analog Input Range, 4 Outputs 12-bit Voltage Output DACs, On-Chip 20ppm/°C Voltage Reference, On-Chip Temperature Sensor (±3°C), Uncommitted Voltage Comparator, JTAG Port, Clocking options: Trimmed On-Chip Oscillator (± 2%), External Watch crystal, External clock source
    45MHz PLL with Programmable Divider, 62k Bytes Flash/EE Memory, 8k Bytes SRAM, In-Circuit Download, JTAG based Debug, Software triggered in-circuit re-programmability, UART, dual I2C and SPI Serial I/O, 14-Pin GPIO Port, 2 X General Purpose Timers, Wake-up and Watchdog Timers, Power Supply Monitor, PLA – Programmable Logic (Array), Power Specified for 3V operation, Active Mode: 6mW (@1MHz) 300mW (@45MHz), Fully specified for –40°C to 85°C operation;
  • DIL-40 (0.6" wide) layout for easy mount on prototype/mother boards
  • RESET button
  • SERIAL DOWNLOAD (bootloader enable) button
  • Green LED status
  • Red power supply LED
  • 32 768 Hz oscillator crystal
  • Power supply filtering capacitors and ferite bead
  • PCB: FR-4, 1.5 mm (0,062"), green soldermask, white silkscreen component print
