MPS430F169 starterkit development board
Price79.95 EUR
10 - 49 pcs71.96 EUR
50 - 10000 pcs63.96 EUR
In stock


  • MCU: MSP430F169 with 60K Bytes Program Flash, 256 Bytes data Flash,2K Bytes RAM
  • 8MB x 8 external NAND Flash memory for data storage (data logging, speech, music etc)
  • LCD 16x2 display with backlight (MSP430 port controllable)
  • Stereo (L-R) microphone inputs with pre-amplifier on A0, A1 ADC inputs
  • Stereo (L-R) linear input with buffer pre-amplifier on A2, A3 ADC inputs
  • Two trimmer potentiometers connected to A4, A5 ADC inputs (useful for volume control etc)
  • Stereo (L-R) linear output on A6,A7 (DAC outputs)
  • Stereo Speaker amplifier with separate volume controls L-R
  • JTAG connector
  • RS232 connector
  • RS232 interface circuit with Tx, Rx signals
  • SPI port connector
  • Dallas touch button port
  • Green and Red status LEDs
  • Three buttons
  • 32 768 Hz oscillator crystal
  • 8Mhz crystal oscillator
  • TEST pin pull-down
  • RST/NMI pin pull-up
  • Power supply voltage regulators and filtering capacitor
  • Power supply plug-in jack for input voltage 7.5-9VDC
  • Extension headers for the free uC pins
  • PCB: FR-4, 1.5 mm (0,062"), green soldermask, white silkscreen component print
  • Dimensions: 120x84 mm (3x1.2")
