AVR-GSM

AVR-GSM
AVR-GSM AVR-GSM AVR-GSM
Development board with ATMEGA32 and 3 band GSM GPRS module 850/900/1800MHZ
Price95.95 EUR
10 - 49 pcs86.36 EUR
50 - 10000 pcs76.76 EUR
In stock

AVR-GSM is an excellent board for adding a remote monitoring and control to remote places by a GSM cellular network. Do you want to switch on/off your local heating in your mountain house? To monitor the temperature at up to 8 remote points and up to 30 meters away from the module? To listen to what happens in your house with silent call after you get a message for an alarm status? Then the AVR-GSM is the board for you!

It contains an ATmega32 microcontroller and a 3-band GSM GPRS module 900/1800/1900Mhz inside which covers the most used GSM networks around the world. The GSM antenna is build in the board so there is no need for any external expensive GSM antennas. AVR-GSM has two relays 240VAC/10A, two optoisolated inputs which could be connected to alarm sensors or just buttons for user actions (like call pre-loaded phone numbers), an on-board temperature sensor and a connector for additional up to 8 addressable remote temperature sensors at up to 30 meter distance from the module. A normal phone hook can be connected to this board to allow the user to speak, listen, take and place phone calls as a normal stand alone cellular phone. The AVR-GSM can be connected to a PC with its USB connector and it is recognized as modem which could be used to provide internet via GPRS to your computer (imagine how useful is this for your mountain house if there is no internet but only a cellular network!).

FEATURES

  • MCU: ATMega32 32KB Flash memory , 2KB RAM, 1KB EEPROM
  • JTAG connector for programming and debugging with AVR-JTAG-L or AVR-JTAG-USB
  • GSM GPRS 3-BAND MODULE 900/1800/1900Mhz with build on-board GSM cellular antenna
  • Temperature sensor built-in the the GSM module
  • Li-ion backup battery for up to 200 hours of GSM module stand-by (no relays etc peripherals active)
  • SIM-card holder
  • Two RELAYS 240VAC/10A
  • Two optoisolated inputs
  • USB interface
  • Phone hook connector
  • Buzzer (ringer)
  • Status LED
  • Pads for on-board temperature digital sensor
  • Connector for remote temperature sensors up to 30meters far away from AVR-GSM
  • Plastic housing (optional)
  • Extension 26 pin connector for all unused ATMega32 ports
  • PCB: FR-4, 1.5 mm (0,062"), soldermask, silkscreen component print
  • Dimensions: 130x82x34 mm (5.1x3.2x1.3")
