LPC-E2214-1MB

LPC-E2214-1MB
Development board for LPC2214 ARM7TDMI-S microcontroller with 1MB external flash, 1MB external SRAM USB, RS232 and ETHERNET
Price117.95 EUR
10 - 49 pcs106.16 EUR
50 - 10000 pcs94.36 EUR
In stock

FEATURES

  • MCU: LPC2214 16/32 bit ARM7TDMI-S™t with 256K Bytes Program Flash, 16K Bytes RAM, EXTERNAL MEMORY BUS, RTC,4x 10 bit ADC 2.44 uS, 2x UARTs, I2C, SPI, 2x 32bit TIMERS, 7x CCR, 6x PWM, WDT, 5V tolerant I/O, up to 60MHz operation
  • Standard JTAG connector with ARM 2x10 pin layout for programming/debugging with ARM-JTAG
  • Optional ETM connector (not installed)
  • 1MB (256Kx32bit) 12 ns 71V416 SRAM
  • 1MB (512Kx16bit) 55ns MX26LV800BTC FLASH or 70 ns ES29LV800EB FLASH
  • Standard JTAG connector with ARM 2x10 pin layout for programming/debugging with ARM-JTAG
  • USB to RS232 convertor, board can take power only from USB port
  • RESET circuit with exterman control of Philips ISP utility via USB-RS232 virtual port
  • Jumpers for boot select from external memory
  • Jumpers for ISP/RUN mode
  • Ethernet controller with CS8900A and RJ45 connector
  • LCD 16x2 DISPLAY with BACKLIGHT
  • 2 BUTTONS
  • POTENTIOMETER connected to ADC
  • SPI connector
  • RS232 driver and connector
  • DALLAS i-BUTTON interface and connector
  • I2C 24LC515 EEPROM on board
  • Two on board voltage regulators 1.8V and 3.3V with up to 800mA current

SOFTWARE
