MSP430-P123M

MSP430-P123M
MPS430F123 prototype board
Price7.95 EUR
10 - 49 pcs7.16 EUR
50 - 10000 pcs6.36 EUR
In Stock

FEATURES

  • MCU: MSP430F123 with 8K Bytes Program Flash, 256 Bytes data Flash, 256 Bytes RAM, hardware UART
  • JTAG connector
  • JTAG Power_In and Power_Out jumpers
  • 32 768 Hz oscillator crystal
  • TEST pin pull-down
  • RST/NMI pin pull-up
  • Power supply connector for battery +3V
  • Power supply filtering capacitor
  • Extension slot on every uC pin
  • Grid 100 mils
  • GND bus
  • Vcc bus
  • Four mounting holes
  • PCB: FR-4, 1.5 mm (0,062"), green soldermask, white silkscreen component print
  • Dimensions: 59x44 mm (2.3x1.7")
