MAXQ-H2000

MAXQ-H2000
MAXQ2000-RAX header board
Price17.95 EUR
10 - 49 pcs16.16 EUR
50 - 10000 pcs14.36 EUR
In stock

FEATURES

  • MCU: MAX2000-RAX up to 20 Mhz( single clock per instruction i.e. up to 20MIPS), low power 190 uA @ 8Mhz, power supply 1.8-2.5V, 16 bit microcontroller with 64 KB Flash (10K re-programming cycles), 2KB RAM, 3x 16bit Timers, 2x UART, 1x SPI, 1-wire, build-in driver for 132 segment LCD
  • JTAG connector
  • 20 Mhz (on socket) and 32 768 Hz oscillator crystal
  • Two on-board power supply voltage regulators supplying +2.5V to core and +3.3V to GPIOs
  • PWR_JTAG allow board to be power supplied by the JTAG (if MAXQ-JTAG-USB is used)
  • Power supply filtering capacitors
  • Extension headers for each uC pin on 0.1" row header
  • PCB: FR-4, 1.5 mm (0,062"), green soldermask, white silkscreen component print
  • Dimensions: 47x47 mm (1.8x1.8")
  • Space between the pin rows: 43.18 mm (1.7")
