SNS-SHTC3B
Breadboard friendly SHTC3 precise temperature and humidity sensor with I2C interface
| Price | 4.95 EUR |
|---|
SNS-SHTC3B is based on Sensirion SHTC3 sensor with i2C interface, temperature measurement accuracy of 0.2C and Humidity measurement accuracy 2%.
Low power, I2C interface.
Compared to SHT30 it is lower power and operates at lower voltages: 1.62-3.6V versa SHT30 which operates from 2.4-5.0V
Low power, I2C interface.
Compared to SHT30 it is lower power and operates at lower voltages: 1.62-3.6V versa SHT30 which operates from 2.4-5.0V
FEATURES
- Supply voltage 1.62-3.6V
- Average current 4.9uA if measure once per second
- Maximum consumption 900uA
- Operating temperature -40 to +125 °C
- Temperature measurement accuracy: 0.2C
- Temperature change response time: 2s
- Operating humidity: 0-100%
- Humidity measurement accuracy 2%
- Humidity change response time: 8s
- SCL clock up to 1Mhz
- I2C address 0x70
- includes 4 jumper wires female-female for connection
