SINGLE SIDE SSS/SSQ PCB PANEL SPECIFICATIONS:

• Panel sizes: SSS 160x100 mm(6.3 x 3.9"), SSQ 320x200 mm (12.6 x 7.8")
• Laminate type: FR-4
• Laminate thickness: 0.5 mm, 0.8 mm, 1.0 mm, 1.5 mm (standard)
• Laminate base copper thickness: 18 um (1/2 oz), 35um (1 oz) (standard)
• Soldermask: single side liquid photoimagable (LPI) green color
• Component print: single side white color ink
• Minimum tracks and spaces: 0,203 mm (0,008")
• Standard drill tools: 0,7 mm (0,028"), 0,9 mm (0,035"), 1.0 mm (0,039"), 1.1 mm (0,043"), 1.3 mm (0,051"), 1.5 mm (0,059"), 2.1 mm (0,083"), 3.3 mm (0,13")
• Number of drill holes: up to 500 for SSS, up to 2000 for SSQ
• PCB finish: immersion gold ENIG ROHS compliant
• De-panelization: cut-to-border only in rectangle shapes
• Turnaround time: 3-5 WORKING DAYS if traces/spaces >= 0,254 mm (0,010"); 15 WORKING DAYS if traces/spaces < 0,254 mm (0,010")
