PIC32-WEB WEB SERVER WITH 32 BIT PIC MICROCONTROLLERS WITH PIC32MX460F512 AND 100 MBIT ETHERNET INTERFACE

FEATURES

• PIC32MX460F512 microcontroller
• note to connect to Ethernet this board requires MOD-ENC624J600 which should be bought separately!
• JTAG connector
• ICSP/ICD connector for programming / debugging with PIC-ICD2-POCKET.
• Reser button
• Reset Circuit
• three User event buttons
• three LEDs
• UEXT connector
• Analogue trimmer potentiometer
• RS232 driver and connector
• Complete web server and TCP-IP stack support as per Microchip's open source TCP-IP stack
• Power plug-in jack for +5VDC power supply
• Voltage regulator +3.3V and filtering capacitors
• Extension header to connect to other boards
• Dimensions 100x60 mm (3.9x2.4")

DOCUMENTS:

• PIC32-WEB.pdf - PIC-WEB users manual
• Microchip TCP/IP AN833 - please read carefully, the TCP/IP stack is described

HARDWARE:

• PIC32-WEB schematic
• PIC ICSP connector

WARNING:

Do not use "programmer-to-go" button when there is no image on the OLIMEX PIC-KIT3 or MICROCHIP PIC-KIT3 or that might put your microcontroller in an inrecoverable state. We have tested the mentioned scenario and we can confirm it destroys PIC32 chips (using both our and the original Microchip PICKIT3). We don't take responsibility if you brick your chip that way. For more info check the following: www.microchip.com/forums/m635420.aspx.

• Microchip TCP-IP Stack 5.00 patch modified for PIC32-WEB
• PIC32-WEB examples PSP mode
• PIC32-WEB examples SPI mode

ORDERING CODES:
		PIC32-WEB completely assembled and tested (note you need MOD-ENC624J600 to connect to Ethernet)
