 * FileName:        mTouchCap_PIC24_CTMU_Physical.h
 * Dependencies:
 * Processor:       PIC24
 * Compiler:       	C30
 * Linker:          MPLAB LINK30
 * Company:         Microchip Technology Incorporated
 *
 * Software License Agreement
 *
 * Copyright © 2009 Microchip Technology Inc.
 * Microchip licenses this software to you solely for use with Microchip products, according to the terms of the
 * accompanying click-wrap software license.  Microchip and its licensors retain all right, title and interest in
 * and to the software.  All rights reserved. This software and any accompanying information is for suggestion only.
 * It shall not be deemed to modify Microchip’s standard warranty for its products.  It is your responsibility to ensure
 * that this software meets your requirements.

 * SOFTWARE IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
 * INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY, TITLE, NON-INFRINGEMENT
 * AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT WILL MICROCHIP OR ITS LICENSORS BE LIABLE
 * FOR ANY DIRECT OR INDIRECT DAMAGES OR EXPENSES INCLUDING BUT NOT LIMITED TO INCIDENTAL,
 * SPECIAL, INDIRECT, PUNITIVE OR CONSEQUENTIAL DAMAGES, LOST PROFITS OR LOST DATA,
 * COST OF PROCUREMENT OF SUBSTITUTE GOODS, TECHNOLOGY OR SERVICES, OR ANY CLAIMS BY THIRD PARTIES
 * (INCLUDING BUT NOT LIMITED TO ANY DEFENSE THEREOF), OR OTHER SIMILAR COSTS.
 * The aggregate and cumulative liability of Microchip and its licensors for damages related to the use of the software
 * will in no event exceed $1000 or the amount you paid Microchip for the software, whichever is greater.

 * MICROCHIP PROVIDES THIS SOFTWARE CONDITIONALLY UPON YOUR ACCEPTANCE OF THESE TERMS AND
 * THE TERMS OF THE ACCOMPANYING CLICK-WRAP SOFTWARE LICENSE.
 *
 *
 * Author               		Date        		Comment
 *~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
 * Naveen. M				    14 Apr 2009			Version 1.0 Initial Draft
 * Sasha. M	/ Naveen. M			4 May 2009  		Version 1.0 Initial Draft
 * Sasha. M	/ Naveen. M			11 Nov 2009  		Version 1.0 Release
 * Sasha. M	/ Nithin. 			10 April 2010  		Version 1.20 Release
 * Nithin M						11 Aug 2010			Implemetation of Low Power Demo
 * Arpitha P 					08 June 2011		Version 1.31 Release
 *****************************************************************************/
#ifndef _MTOUCH_PIC24_CTMU_PHYSICAL_H
#define _MTOUCH_PIC24_CTMU_PHYSICAL_H

/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */
/* ~~~~~~~~~~~~~~~~~~~~~	Includes	~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~  	*/
/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */
#include 		"Config.h"
#ifdef USE_MTOUCH_AND_GRAPHICS
	#include 		"mTouchCap_Config.h"
	#include 		"mTouchCap_HardwareProfile.h"
#else
	#include 		"HardwareProfile.h"
#endif
#ifndef			USE_MTOUCH_AND_GRAPHICS
	#include 		"mTouchCap_Timers.h"
#endif
#include 		"mTouchCap_Adc.h"
#include 		"GenericTypeDefs.h"

#ifdef __PIC24F__

/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */
/* ~~~~~~~~~~~~~~~~~~~~~	Constants	~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~  	*/
/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */


/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */
/* ~~~~~~~~~~~~~~~~~~~~~	Variables  	~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~  	*/
/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */


/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */
/* ~~~~~~~~~~~~~~~~~~~~~	Externs  	~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~  	*/
/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */
extern WORD curBigData		[MAX_ADC_CHANNELS]; //Storage for CTMU values
extern WORD	curRawData		[MAX_ADC_CHANNELS];	//Storage for CTMU channel values
extern WORD	tripValue   	[MAX_ADC_CHANNELS];	//Storage for the trip point for each channel
extern WORD	hystValue   	[MAX_ADC_CHANNELS];	//Storage for the hysterisis value for each channel
extern WORD	pressedCount   	[MAX_ADC_CHANNELS];	//Storage for count of pressed value for each channel
extern WORD	unpressedCount  [MAX_ADC_CHANNELS];	//Storage for count of unpressed value for each channel
extern WORD	avg_delay 		[MAX_ADC_CHANNELS]; //Storage for count for average update for each channel
extern WORD	averageData 	[MAX_ADC_CHANNELS];	// running average of CTMU channels
extern WORD	smallAvg		[MAX_ADC_CHANNELS];	// current button small avg
extern WORD	actualValue		[MAX_ADC_CHANNELS];	// actual raw A/D counts for each channel
extern WORD	channel_TRIM_value	[MAX_ADC_CHANNELS];//Trim value of the channels
extern WORD	channel_IRNG_value	[MAX_ADC_CHANNELS];//Value of current to all the channels
extern BYTE	chFilterType	[MAX_ADC_CHANNELS];	// Channel filter type
extern BYTE	chDecodeMethod	[MAX_ADC_CHANNELS];	// decode method type
extern BYTE Press_State 	[MAX_ADC_CHANNELS]; // Storage for the pressed state
extern SHORT startupCount;						// variable to 'discard' first N samples
extern SHORT loopCount; 						// Storage of count for loop
extern WORD	immediateValue;						// current button value
extern WORD	scaledBigValue;						// current button bigval

/* array for different analog channels */
extern WORD channelIndex[MAX_ADC_CHANNELS];
extern BYTE Channel_Pressed_Status[MAX_ADC_CHANNELS];
/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */
/* ~~~~~~~~~~~~~~~~~~~~~	Function Prototypes  ~~~~~~~~~~~~~~~~~~~~~~~~~~  	*/
/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */
void mTouchCapPhy_Init(void);
void mTouchCapApp_PortSetup(void);
void mTouchCapPhy_CTMUSetup(void);
void mTouchCapPhy_AdcSetup(void);
void mTouchCapPhy_ReadCTMU(WORD Index);
void mTouchCapPhy_ChannelSetup(WORD ChannelNum);
void mTouchCapPhy_InitCTMU(void);
void mTouchCapPhy_ChargeTimeInit(void);
void mTouchCapPhy_Init(void);
void mTouchCapPhy_SequenceChannels(void);
void mTouchCapPhy_SetupCurrentSourceRange(WORD CurrentSourceRange);
void mTouchCapPhy_SetTrimValue( WORD TrimValue);
void mTouchCapPhy_Discharge_Current (void);
void mTouchCapPhy_Charge_Current (void);
WORD mTouchCapPhy_Read_ADC();
void CTMU_Current_trim_config(int channel_no);
void DynamicTripValueCalculation(WORD Index);
void mTouchCapPhy_AverageData(WORD Index);
void mTouchCapPhy_StablizeChannelData(void);
/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */
/* ~~~~~~~~~~~~~~~~~~~~~	Enums      ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~  	*/
/* ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ */

/***********************************************************************/
/********************	End of PORTS  	********************************/
/***********************************************************************/
/***********************************************************************/


/***************************************************************************************/
/********************ANALOG CHANNELS TRISBITS DEFINITION********************************/
/***************************************************************************************/
#ifdef  ADC_LEGACY 											//To Configure Port pin as Analog by clearing the port pin

#define DIGITAL                   1							//Set port pin to make it as Digital I/O
#define ANALOG	                  0							//Clear port pin to make it as Analog

/*******Initialization of Analog channels for 24F04KA200 and 24F16KA101 Family devices ********/
#if defined(__PIC24F04KA200__) || defined(__PIC24F04KA201__)||  defined(__PIC24F08KA101__)\
|| defined(__PIC24F08KA102__)  || defined(__PIC24F16KA101__)  || defined(__PIC24F16KA102__)

#define TRIS_CHANNEL_AN0				TRISAbits.TRISA0				//To select Port pin as Input or output
#define TRIS_CHANNEL_AN1  				TRISAbits.TRISA1
#define TRIS_CHANNEL_AN2  				TRISAbits.TRISA4
#define TRIS_CHANNEL_AN3  				TRISBbits.TRISB4
#define TRIS_CHANNEL_AN4  				TRISBbits.TRISB7
#define TRIS_CHANNEL_AN5  				TRISBbits.TRISB8
#define TRIS_CHANNEL_AN6  				TRISBbits.TRISB9
#define TRIS_CHANNEL_AN7  				TRISBbits.TRISB14
#define TRIS_CHANNEL_AN8  				TRISBbits.TRISB15


#define ADC_CHANNEL_AN0(Value) 		AD1PCFGbits.PCFG0 = Value;			//To make Port pin as Analog or Digital I/O
#define ADC_CHANNEL_AN1(Value) 		AD1PCFGbits.PCFG1 = Value;
#define ADC_CHANNEL_AN2(Value) 		AD1PCFGbits.PCFG2 = Value;
#define ADC_CHANNEL_AN3(Value) 		AD1PCFGbits.PCFG3 = Value;
#define ADC_CHANNEL_AN4(Value) 		AD1PCFGbits.PCFG4 = Value;
#define ADC_CHANNEL_AN5(Value) 		AD1PCFGbits.PCFG5 = Value;
#define ADC_CHANNEL_AN6(Value) 		AD1PCFGbits.PCFG10 = Value;
#define ADC_CHANNEL_AN7(Value) 		AD1PCFGbits.PCFG11 = Value;
#define ADC_CHANNEL_AN8(Value) 		AD1PCFGbits.PCFG12 = Value;

/******** Initialization of Analog channels for 24FJ32GA102 and 24FJ32GB104 Family devices ********/
#elif defined(__PIC24FJ32GA102__) || defined(__PIC24FJ32GA104__) || defined(__PIC24FJ64GA102__)\
 || defined(__PIC24FJ64GA104__) || defined(__PIC24FJ32GB002__) || defined(__PIC24FJ32GB004__)\
 || defined(__PIC24FJ64GB002__) || defined(__PIC24FJ64GB004__)

#define TRIS_CHANNEL_AN0				TRISBbits.TRISB0				//To select Port pin as Input or output
#define TRIS_CHANNEL_AN1  				TRISBbits.TRISB1
#define TRIS_CHANNEL_AN2  				TRISBbits.TRISB2
#define TRIS_CHANNEL_AN3  				TRISBbits.TRISB3
#define TRIS_CHANNEL_AN4  				TRISBbits.TRISB4
#define TRIS_CHANNEL_AN5  				TRISBbits.TRISB5
#define TRIS_CHANNEL_AN6  				TRISBbits.TRISB7
#define TRIS_CHANNEL_AN7  				TRISBbits.TRISB8
#define TRIS_CHANNEL_AN8  				TRISBbits.TRISB9
#define TRIS_CHANNEL_AN9  				TRISBbits.TRISB10
#define TRIS_CHANNEL_AN1O  				TRISBbits.TRISB11
#define TRIS_CHANNEL_AN11  				TRISBbits.TRISB13


#define ADC_CHANNEL_AN0(Value) 		AD1PCFGbits.PCFG0 = Value;			//To make Port pin as Analog or Digital I/O
#define ADC_CHANNEL_AN1(Value) 		AD1PCFGbits.PCFG1 = Value;
#define ADC_CHANNEL_AN2(Value) 		AD1PCFGbits.PCFG2 = Value;
#define ADC_CHANNEL_AN3(Value) 		AD1PCFGbits.PCFG3 = Value;
#define ADC_CHANNEL_AN4(Value) 		AD1PCFGbits.PCFG4 = Value;
#define ADC_CHANNEL_AN5(Value) 		AD1PCFGbits.PCFG5 = Value;
#define ADC_CHANNEL_AN6(Value) 		AD1PCFGbits.PCFG9 = Value;
#define ADC_CHANNEL_AN7(Value) 		AD1PCFGbits.PCFG10 = Value;
#define ADC_CHANNEL_AN8(Value) 		AD1PCFGbits.PCFG11 = Value;
#define ADC_CHANNEL_AN9(Value) 		AD1PCFGbits.PCFG13 = Value;
#define ADC_CHANNEL_AN10(Value)		AD1PCFGbits.PCFG14 = Value;
#define ADC_CHANNEL_AN11(Value)		AD1PCFGbits.PCFG15 = Value;


#else

/******** Initialization of Analog channels for 24FJ128GA110 & 24FJ128GB110 Family devices********/
#define TRIS_CHANNEL_AN0				TRISBbits.TRISB0				//To select Port pin as Input or output
#define TRIS_CHANNEL_AN1  				TRISBbits.TRISB1
#define TRIS_CHANNEL_AN2  				TRISBbits.TRISB2
#define TRIS_CHANNEL_AN3  				TRISBbits.TRISB3
#define TRIS_CHANNEL_AN4  				TRISBbits.TRISB4
#define TRIS_CHANNEL_AN5  				TRISBbits.TRISB5
#define TRIS_CHANNEL_AN6  				TRISBbits.TRISB6
#define TRIS_CHANNEL_AN7  				TRISBbits.TRISB7
#define TRIS_CHANNEL_AN8  				TRISBbits.TRISB8
#define TRIS_CHANNEL_AN9  				TRISBbits.TRISB9
#define TRIS_CHANNEL_AN1O  				TRISBbits.TRISB10
#define TRIS_CHANNEL_AN11  				TRISBbits.TRISB11
#define TRIS_CHANNEL_AN12  				TRISBbits.TRISB12
#define TRIS_CHANNEL_AN13  				TRISBbits.TRISB13
#define TRIS_CHANNEL_AN14  				TRISBbits.TRISB14
#define TRIS_CHANNEL_AN15  				TRISBbits.TRISB15
#define TRIS_CHANNEL_AN16  				TRISCbits.TRISC1
#define TRIS_CHANNEL_AN17  				TRISCbits.TRISC2


#define ADC_CHANNEL_AN0(Value) 		AD1PCFGbits.PCFG0 = Value;			//To make Port pin as Analog or Digital I/O
#define ADC_CHANNEL_AN1(Value) 		AD1PCFGbits.PCFG1 = Value;
#define ADC_CHANNEL_AN2(Value) 		AD1PCFGbits.PCFG2 = Value;
#define ADC_CHANNEL_AN3(Value) 		AD1PCFGbits.PCFG3 = Value;
#define ADC_CHANNEL_AN4(Value) 		AD1PCFGbits.PCFG4 = Value;
#define ADC_CHANNEL_AN5(Value) 		AD1PCFGbits.PCFG5 = Value;
#define ADC_CHANNEL_AN6(Value) 		AD1PCFGbits.PCFG6 = Value;
#define ADC_CHANNEL_AN7(Value) 		AD1PCFGbits.PCFG7 = Value;
#define ADC_CHANNEL_AN8(Value) 		AD1PCFGbits.PCFG8 = Value;
#define ADC_CHANNEL_AN9(Value) 		AD1PCFGbits.PCFG9 = Value;
#define ADC_CHANNEL_AN10(Value)		AD1PCFGbits.PCFG10 = Value;
#define ADC_CHANNEL_AN11(Value)		AD1PCFGbits.PCFG11 = Value;
#define ADC_CHANNEL_AN12(Value)		AD1PCFGbits.PCFG12 = Value;
#define ADC_CHANNEL_AN13(Value)		AD1PCFGbits.PCFG13 = Value;
#define ADC_CHANNEL_AN14(Value)		AD1PCFGbits.PCFG14 = Value;
#define ADC_CHANNEL_AN15(Value)		AD1PCFGbits.PCFG15 = Value;
#define ADC_CHANNEL_AN16(Value)		AD1PCFGHbits.PCFG16 = Value;
#define ADC_CHANNEL_AN17(Value)		AD1PCFGHbits.PCFG17 = Value;

#endif

#endif

#ifdef  ADC_NEW									//To Configure Port pin as Analog by setting the port pin

#define DIGITAL                 	0			//Clear port pin to make it as Digital I/O
#define ANALOG	                	1			//Set port pin to make it as Analog

/******** Initialization of Analog channels for 24F16KA304 & 24FV16KA304 Family devices ********/
#if defined(__PIC24F16KA301__)   || defined (__PIC24F16KA302__)  || defined(__PIC24F16KA304__)\
||  defined(__PIC24F32KA301__)   || defined (__PIC24F32KA302__)  || defined(__PIC24F32KA304__)\
||  defined(__PIC24FV16KA301__)  || defined (__PIC24FV16KA302__) || defined(__PIC24FV16KA304__)\
||  defined(__PIC24FV32KA301__)  || defined (__PIC24FV32KA302__) || defined(__PIC24FV32KA304__)


#define TRIS_CHANNEL_AN0  				TRISAbits.TRISA0			//To select Port pin as Input or output
#define TRIS_CHANNEL_AN1  				TRISAbits.TRISA1
#define TRIS_CHANNEL_AN2  				TRISAbits.TRISA2
#define TRIS_CHANNEL_AN3  				TRISAbits.TRISA3
#define TRIS_CHANNEL_AN4  				TRISBbits.TRISB0
#define TRIS_CHANNEL_AN5  				TRISBbits.TRISB1
#define TRIS_CHANNEL_AN6  				TRISBbits.TRISB2
#define TRIS_CHANNEL_AN7 				TRISBbits.TRISB4
#define TRIS_CHANNEL_AN8  				TRISBbits.TRISB12
#define TRIS_CHANNEL_AN9  				TRISBbits.TRISB13
#define TRIS_CHANNEL_AN10  				TRISBbits.TRISB14
#define TRIS_CHANNEL_AN11  				TRISBbits.TRISB15


#define ADC_CHANNEL_AN0(Value) 			_ANSA0 = Value;		//To make Port pin as Analog or Digital I/O
#define ADC_CHANNEL_AN1(Value) 			_ANSA1 = Value;
#define ADC_CHANNEL_AN2(Value) 			_ANSA2 = Value;
#define ADC_CHANNEL_AN3(Value) 			_ANSA3 = Value;
#define ADC_CHANNEL_AN4(Value) 			_ANSB0 = Value;
#define ADC_CHANNEL_AN5(Value) 			_ANSB1 = Value;
#define ADC_CHANNEL_AN6(Value) 			_ANSB2 = Value;
#define ADC_CHANNEL_AN7(Value) 			_ANSB4 = Value;
#define ADC_CHANNEL_AN8(Value)			_ANSB12= Value;
#define ADC_CHANNEL_AN9(Value)			_ANSB13= Value;
#define ADC_CHANNEL_AN10(Value)			_ANSB14= Value;
#define ADC_CHANNEL_AN11(Value)			_ANSB15= Value;


/* Initialization of Analog channels for  24FJ128DA206 & 24FJ128GB206 (64 pin devices)Family devices */
#elif defined(__PIC24FJ128DA106__) ||  defined(__PIC24FJ128DA206__) || defined(__PIC24FJ256DA106__)\
 || defined(__PIC24FJ256DA206__) ||  defined(__PIC24FJ128GB206__) || defined(__PIC24FJ256GB206__)

#define TRIS_CHANNEL_AN0  				TRISBbits.TRISB0			//To select Port pin as Input or output
#define TRIS_CHANNEL_AN1  				TRISBbits.TRISB1
#define TRIS_CHANNEL_AN2  				TRISBbits.TRISB2
#define TRIS_CHANNEL_AN3  				TRISBbits.TRISB3
#define TRIS_CHANNEL_AN4  				TRISBbits.TRISB4
#define TRIS_CHANNEL_AN5  				TRISBbits.TRISB5
#define TRIS_CHANNEL_AN6  				TRISBbits.TRISB6
#define TRIS_CHANNEL_AN7  				TRISBbits.TRISB7
#define TRIS_CHANNEL_AN8  				TRISBbits.TRISB8
#define TRIS_CHANNEL_AN9  				TRISBbits.TRISB9
#define TRIS_CHANNEL_AN1O  				TRISBbits.TRISB10
#define TRIS_CHANNEL_AN11  				TRISBbits.TRISB11
#define TRIS_CHANNEL_AN12  				TRISBbits.TRISB12
#define TRIS_CHANNEL_AN13  				TRISBbits.TRISB13
#define TRIS_CHANNEL_AN14  				TRISBbits.TRISB14
#define TRIS_CHANNEL_AN15  				TRISBbits.TRISB15


#define ADC_CHANNEL_AN0(Value) 		ANSBbits.ANSB0 = Value;			//To make Port pin as Analog or Digital I/O
#define ADC_CHANNEL_AN1(Value) 		ANSBbits.ANSB1 = Value;
#define ADC_CHANNEL_AN2(Value) 		ANSBbits.ANSB2 = Value;
#define ADC_CHANNEL_AN3(Value) 		ANSBbits.ANSB3 = Value;
#define ADC_CHANNEL_AN4(Value) 		ANSBbits.ANSB4 = Value;
#define ADC_CHANNEL_AN5(Value) 		ANSBbits.ANSB5 = Value;
#define ADC_CHANNEL_AN6(Value) 		ANSBbits.ANSB6 = Value;
#define ADC_CHANNEL_AN7(Value) 		ANSBbits.ANSB7 = Value;
#define ADC_CHANNEL_AN8(Value) 		ANSBbits.ANSB8 = Value;
#define ADC_CHANNEL_AN9(Value) 		ANSBbits.ANSB9 = Value;
#define ADC_CHANNEL_AN10(Value)		ANSBbits.ANSB10 = Value;
#define ADC_CHANNEL_AN11(Value)		ANSBbits.ANSB11= Value;
#define ADC_CHANNEL_AN12(Value)		ANSBbits.ANSB12= Value;
#define ADC_CHANNEL_AN13(Value)		ANSBbits.ANSB13= Value;
#define ADC_CHANNEL_AN14(Value)		ANSBbits.ANSB14= Value;
#define ADC_CHANNEL_AN15(Value)		ANSBbits.ANSB15= Value;

#else

#define TRIS_CHANNEL_AN0  				TRISBbits.TRISB0				//To select Port pin as Input or output
#define TRIS_CHANNEL_AN1  				TRISBbits.TRISB1
#define TRIS_CHANNEL_AN2  				TRISBbits.TRISB2
#define TRIS_CHANNEL_AN3  				TRISBbits.TRISB3
#define TRIS_CHANNEL_AN4  				TRISBbits.TRISB4
#define TRIS_CHANNEL_AN5  				TRISBbits.TRISB5
#define TRIS_CHANNEL_AN6  				TRISBbits.TRISB6
#define TRIS_CHANNEL_AN7  				TRISBbits.TRISB7
#define TRIS_CHANNEL_AN8  				TRISBbits.TRISB8
#define TRIS_CHANNEL_AN9  				TRISBbits.TRISB9
#define TRIS_CHANNEL_AN1O  				TRISBbits.TRISB10
#define TRIS_CHANNEL_AN11  				TRISBbits.TRISB11
#define TRIS_CHANNEL_AN12  				TRISBbits.TRISB12
#define TRIS_CHANNEL_AN13  				TRISBbits.TRISB13
#define TRIS_CHANNEL_AN14  				TRISBbits.TRISB14
#define TRIS_CHANNEL_AN15  				TRISBbits.TRISB15
#define TRIS_CHANNEL_AN16  				TRISCbits.TRISC4
#define TRIS_CHANNEL_AN17  				TRISGbits.TRISG6
#define TRIS_CHANNEL_AN18 				TRISGbits.TRISG7
#define TRIS_CHANNEL_AN19  				TRISGbits.TRISG8
#define TRIS_CHANNEL_AN20  				TRISGbits.TRISG9
#define TRIS_CHANNEL_AN21  				TRISEbits.TRISE9
#define TRIS_CHANNEL_AN22  				TRISAbits.TRISA6
#define TRIS_CHANNEL_AN23  				TRISAbits.TRISA7



#define ADC_CHANNEL_AN0(Value) 		ANSBbits.ANSB0 = Value;				//To make Port pin as Analog or Digital I/O
#define ADC_CHANNEL_AN1(Value) 		ANSBbits.ANSB1 = Value;
#define ADC_CHANNEL_AN2(Value) 		ANSBbits.ANSB2 = Value;
#define ADC_CHANNEL_AN3(Value) 		ANSBbits.ANSB3 = Value;
#define ADC_CHANNEL_AN4(Value) 		ANSBbits.ANSB4 = Value;
#define ADC_CHANNEL_AN5(Value) 		ANSBbits.ANSB5 = Value;
#define ADC_CHANNEL_AN6(Value) 		ANSBbits.ANSB6 = Value;
#define ADC_CHANNEL_AN7(Value) 		ANSBbits.ANSB7 = Value;
#define ADC_CHANNEL_AN8(Value) 		ANSBbits.ANSB8 = Value;
#define ADC_CHANNEL_AN9(Value) 		ANSBbits.ANSB9 = Value;
#define ADC_CHANNEL_AN10(Value)		ANSBbits.ANSB10 = Value;
#define ADC_CHANNEL_AN11(Value)		ANSBbits.ANSB11= Value;
#define ADC_CHANNEL_AN12(Value)		ANSBbits.ANSB12= Value;
#define ADC_CHANNEL_AN13(Value)		ANSBbits.ANSB13= Value;
#define ADC_CHANNEL_AN14(Value)		ANSBbits.ANSB14= Value;
#define ADC_CHANNEL_AN15(Value)		ANSBbits.ANSB15= Value;

#define ADC_CHANNEL_AN16(Value)		ANSCbits.ANSC4 = Value;
#define ADC_CHANNEL_AN17(Value)		ANSGbits.ANSG6 = Value;
#define ADC_CHANNEL_AN18(Value)		ANSGbits.ANSG7 = Value;
#define ADC_CHANNEL_AN19(Value)		ANSGbits.ANSG8 = Value;

#define ADC_CHANNEL_AN20(Value)		ANSGbits.ANSG9 = Value;
#define ADC_CHANNEL_AN21(Value)		ANSEbits.ANSE9 = Value;
#define ADC_CHANNEL_AN22(Value)		ANSAbits.ANSA7 = Value;
#define ADC_CHANNEL_AN23(Value)		ANSAbits.ANSA6 = Value;

#endif

#endif


/***********************************************************************/
/********************A   D    C*****************************************/
/***********************************************************************/
/***********************************************************************/
#define 	INIT_AD1PCFGL_VALUE		0x0000
#define 	INIT_AD1PCFGH_VALUE		0x0000
#define 	INIT_AD1CON1_VALUE		0x0000
#define 	INIT_AD1CHS_VALUE		0x0000			//select the analog channel 0

/***********************************************************************
Macro      : EnableIntADC1
Overview   : This macro enables the ADC interrupt.
Parameters : None
Remarks    : This macro sets ADC Interrupt Enable bit of Interrupt
             Enable Control Register.
************************************************************************/
#define EnableIntADC1                (IEC0bits.AD1IE = 1)

/***********************************************************************
Macro      : DisableIntADC1
Overview   : This macro disables the ADC interrupt.
Parameters : None
Remarks    : This macro clears ADC Interrupt Enable bit of Interrupt
             Enable Control register.
************************************************************************/
#define DisableIntADC1                (IEC0bits.AD1IE = 0)

/***********************************************************************
Macro      : SetPriorityIntADC1(priority)
Overview   : This macro sets priority for ADC interrupt.
Parameters : priority - This input parameter is the level of interrupt priority
Remarks    : This macro sets ADC Interrupt Priority bits of Interrupt
             Priority Control register.
************************************************************************/
#define SetPriorityIntADC1(priority)     (IPC3bits.AD1IP = priority)

/*******************************************************************
Macro       : ADC1_Clear_Intr_Status_Bit
Overview    : Macro to Clear ADC Interrupt Status bit
Parameters  : None
Remarks     : None
*******************************************************************/
#define ADC1_Clear_Intr_Status_Bit (IFS0bits.AD1IF = 0)

/*******************************************************************
Macro       : ADC1_IF_Bit
Overview    : returns ADC1 Interrupt Flag
Parameters  : None
Remarks     : None
*******************************************************************/
#define ADC1_IF_Bit (IFS0bits.AD1IF)


/************************************************************************
Macro       : BusySampADC1
Overview    : This function is identical to ConvertADC10
Parameters  : None
Remarks     : This macro clears the ADCON1<SAMP> bit and thus stops sampling
              and starts conversion.
**************************************************************************/
#define BusySampADC1              !(AD1CON1bits.SAMP)

/************************************************************************
Macro       : EnableADC1
Overview    : This function enables the ADC module
Parameters  : None
Remarks     : None.
**************************************************************************/
#define EnableADC1                (AD1CON1bits.ADON = 1)

/************************************************************************
Macro       : DisableADC1
Overview    : This function disables the ADC module
Parameters  : None
Remarks     : None.
**************************************************************************/
#define DisableADC1                (AD1CON1bits.ADON = 0)

/************************************************************************
Macro       : Set_Adc_Enable_State
Overview    : This function enables or disable the ADC module depending upon the value.
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Set_Adc_Enable_State(Value)          (AD1CON1bits.ADON = Value)


/************************************************************************
Macro       : Enable_ADC_Sampling
Overview    : This function starts the A/D conversion.
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enable_ADC_Sampling       (AD1CON1bits.SAMP = 1)


/************************************************************************
Macro       : Disable_ADC_Sampling
Overview    : This function starts the A/D conversion.
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Disable_ADC_Sampling       (AD1CON1bits.SAMP = 0)

/************************************************************************
Macro       : ADC_Done_Bit
Overview    : This function declares the AD1CON1bits.DONE.
Parameters  : None
Remarks     : None.
**************************************************************************/
#define ADC_Done_Bit       			 (AD1CON1bits.DONE)

/************************************************************************
Macro       : Adc_Port_Configuration
Overview    : Configure ADC Port pin as Analog or Digital
Parameters  : None
Remarks     : None.
**************************************************************************/
#ifdef ADC_LEGACY
#ifdef PIC24F_LOW_PIN_DEVICE
#define Adc_Port_Configuration(Value)	 (AD1PCFG = Value)  // Configure ADC port for Low Pin Devices
#else
#define Adc_Port_Configuration(Value)	 (AD1PCFGL = Value)	// Configure ADC port
#define Adc_Port_Hgh_Configuration(Value)(AD1PCFGH = Value) // Configure ADC port
#endif
#endif

#ifdef ADC_NEW

#if defined(__PIC24F16KA301__)   || defined (__PIC24F16KA302__)  || defined(__PIC24F16KA304__)\
||  defined(__PIC24F32KA301__)   || defined (__PIC24F32KA302__)  || defined(__PIC24F32KA304__)\
||  defined(__PIC24FV16KA301__)  || defined (__PIC24FV16KA302__) || defined(__PIC24FV16KA304__)\
||  defined(__PIC24FV32KA301__)  || defined (__PIC24FV32KA302__) || defined(__PIC24FV32KA304__)

#if __C30_VERSION__ < 330
#define ANSA  ANSELA										// The SFR name in C-30 3.25 is ANSELA and that needs to be replaced by ANSA
#define ANSB  ANSELB										// according to C-30 3.30 compiler ,data sheet and the code
#define ANSC  ANSELC
#endif

#define Adc_PortA_Configuration(Value)	(ANSA = Value)		// Configure ADC port
#define Adc_PortB_Configuration(Value)	(ANSB = Value)
#define Adc_PortC_Configuration(Value)	(ANSC = Value)

#else

#define Adc_PortA_Configuration(Value)	(ANSA = Value)			// Configure ADC port
#define Adc_PortB_Configuration(Value)	(ANSB = Value)
#define Adc_PortC_Configuration(Value)	(ANSC = Value)
#define Adc_PortD_Configuration(Value)	(ANSD = Value)
#define Adc_PortE_Configuration(Value)	(ANSE = Value)
#define Adc_PortF_Configuration(Value)	(ANSF = Value)
#define Adc_PortG_Configuration(Value)	(ANSG = Value)
#endif

#endif

/************************************************************************

		 Redefining ADC Register

**************************************************************************/
#if defined(__PIC24FJ64GA108__)  || defined(__PIC24FJ64GA110__)
#define ADC_CHANNEL_SELECT 			AD1CHS0
#else
#define ADC_CHANNEL_SELECT 			AD1CHS
#endif
#define ADCSSL						AD1CSSL
#define ADCON3  					AD1CON3
#define ADCON2						AD1CON2
#define ADCON1						AD1CON1
#define ADCBUF						ADC1BUF0


/*Registers Defaults*/
#define ADCSSL_VAL    				 0x0000
#define ADCON3_VAL    				 0x0000
#define ADCON2_VAL    				 0x0000
#define ADCON1_VAL    				 0x0000
#define ADC_PRIORITY				 0x00
#define ADC_PORT_CONFIG_DEFAULT_VALUE 	 0x0000			// Default Value of ADC Port Configuration Register.

#ifdef ADC_NEW

#if defined(__PIC24F16KA301__)   || defined (__PIC24F16KA302__)  || defined(__PIC24F16KA304__)\
||  defined(__PIC24F32KA301__)   || defined (__PIC24F32KA302__)  || defined(__PIC24F32KA304__)\
||  defined(__PIC24FV16KA301__)  || defined (__PIC24FV16KA302__) || defined(__PIC24FV16KA304__)\
||  defined(__PIC24FV32KA301__)  || defined (__PIC24FV32KA302__) || defined(__PIC24FV32KA304__)
#define ADC_PORTA_CONFIG_DEFAULT_VALUE 	0x000F			// Default Value of ADC Port Configuration Register.
#define ADC_PORTB_CONFIG_DEFAULT_VALUE 	0xF017

#elif defined(__PIC24FJ128DA106__) ||  defined(__PIC24FJ128DA206__) || defined(__PIC24FJ256DA106__)\
 || defined(__PIC24FJ256DA206__) ||  defined(__PIC24FJ128GB206__) || defined(__PIC24FJ256GB206__)
#define ADC_PORTB_CONFIG_DEFAULT_VALUE 	0xFFFF			// Default Value of ADC Port Configuration Register.

#else
#define ADC_PORTA_CONFIG_DEFAULT_VALUE 	0x00C0			// Default Value of ADC Port Configuration Register.
#define ADC_PORTB_CONFIG_DEFAULT_VALUE 	0xFFFF
#define ADC_PORTC_CONFIG_DEFAULT_VALUE 	0x0010
#define ADC_PORTE_CONFIG_DEFAULT_VALUE 	0x0200

#ifdef  USE_MTOUCH_AND_GRAPHICS
	#define ADC_PORTG_CONFIG_DEFAULT_VALUE 	0x0180
#else
	#define ADC_PORTG_CONFIG_DEFAULT_VALUE 	0x03C0
#endif
#endif
#endif

/*AD1CON1 register definition*/
#define ADC_MODULE_ON               0x8000 /* A/D Converter on */
#define ADC_MODULE_OFF              0x0000 /* A/D Converter off */
#define ADC_MODULE_MASK             (~ADC_MODULE_ON)  /* A/D Converter mask*/
#define ADC_IDLE_CONTINUE           0x0000 /* A/D Operate in Idle mode */
#define ADC_IDLE_STOP               0x2000 /* A/D Stop in Idle mode */
#define ADC_IDLE_MASK               (~ADC_IDLE_CONTINUE) /* A/D Idle mode mask */
#define ADC_FORMAT_SIGN_FRACT       0x0300 /* A/D data format signed fractional */
#define ADC_FORMAT_FRACT            0x0200 /* A/D data format fractional */
#define ADC_FORMAT_SIGN_INT         0x0100 /* A/D data format signed integer */
#define ADC_FORMAT_INTG             0x0000 /* A/D data format integer */
#define ADC_FORMAT_MASK             (~ADC_FORMAT_SIGN_FRACT)/* A/D format mask */
#define ADC_CLK_AUTO                0x00E0 /* Internal counter ends sampling and starts conversion (Auto convert) */
#define ADC_CLK_CTMU                0x0080 /* CTMU event ends sampling and starts conversion */
#define ADC_CLK_TMR5                0x0060 /* Timer5 compare ends sampling and starts conversion */
#define ADC_CLK_TMR3                0x0040 /* Timer3 compare ends sampling and starts conversion */
#define ADC_CLK_INT0                0x0020 /* Active transition on INT0 ends sampling and starts conversion */
#define ADC_CLK_MANUAL              0x0000 /* Clearing sample (SAMP) bit ends sampling and starts conversion */
#define ADC_CLK_MASK                (~ADC_CLK_AUTO) /* A/D clock mask */
#define ADC_AUTO_SAMPLING_ON        0x0004 /* Sampling begins immediately after last conversion */
#define ADC_AUTO_SAMPLING_OFF       0x0000 /* Sampling begins when SAMP bit is set */
#define ADC_AUTO_SAMPLING_MASK      (~ADC_AUTO_SAMPLING_ON) /* A/D auto sampling mask */
#define ADC_SAMP_ON                 0x0002 /* sample / hold amplifiers are sampling */
#define ADC_SAMP_OFF                0x0000 /* sample / hold amplifiers are holding */
#define ADC_SAMP_MASK               (~ADC_SAMP_ON) /* A/D sampling mask */

/*AD1CON2 control register definition*/
#define ADC_VREF_EXT_AVSS           0x2000 /* A/D Voltage reference configuration Vref+ external and Vref- is AVss */
#define ADC_VREF_AVDD_EXT           0x4000 /* A/D Voltage reference configuration Vref+ AVdd and Vref- external */
#define ADC_VREF_EXT_EXT            0x6000 /* A/D Voltage reference configuration both Vref+ and Vref- are external */
#define ADC_VREF_AVDD_AVSS          0x8000 /* A/D Voltage reference configuration Vref+ is AVdd and Vref- is AVss */
#define ADC_VREF_MASK               (~(ADC_VREF_AVDD_AVSS | ADC_VREF_EXT_EXT)) /* A/D Vref  mask */
#define ADC_SCAN_ON                 0x0400 /* A/D Scan Input Selections for CH0 during SAMPLE A */
#define ADC_SCAN_OFF                0x0000 /* A/D Do notScan Input Selections for CH0+ during SAMPLE A */
#define ADC_SCAN_ON_OFF_MASK        (~ADC_SCAN_ON) /* A/D scan input mask */

#define ADC_INTR_CONV             	0x0000 /* Interrupts at the completion of conversion of 2 samples */

#define ADC_ALT_BUF_ON              0x0002 /* Buffer configured as 2 8-word buffers */
#define ADC_ALT_BUF_OFF             0x0000 /* Buffer configured as 1 16-word buffer */
#define ADC_ALT_BUF_MASK            (~ADC_ALT_BUF_ON) /* A/D alternate buffer mask */
/* A/D Uses channel input selects for SAMPLE A on first sample and SAMPLE B on next sample */
#define ADC_ALT_INPUT_ON            0x0001 /* alternate between MUXA and MUXB */
/* A/D Always uses channel input selects for SAMPLE A */
#define ADC_ALT_INPUT_OFF           0x0000 /* use MUXA only */
#define ADC_ALT_MASK                (~ADC_ALT_INPUT_ON) /* A/D alternate input mask */

/*AD1CON3 register definition*/
#define ADC_CONV_CLK_INTERNAL_RC    0x8000 /* A/D internal RC clock */
#define ADC_CONV_CLK_SYSTEM         0x0000 /* Clock derived from system clock */
#define ADC_CONV_CLK_SOURCE_MASK    (~ADC_CONV_CLK_INTERNAL_RC) /* A/D conversion clock mask */

#define ADC_SAMPLE_TIME           	0x0000 /* A/D Auto Sample Time 0 Tad */
#define ADC_CONV_CLK_Tcy          	0x0000 /* A/D Conversion Clock is 1*Tcy */

/*AD1CSSL control register definition*/
#define ADC_SCAN_AN      			0x0000 /*Enable Input Scan AN0 */


#define ADC_CONFIG_ADCON1  (ADCON1_VAL | ADC_MODULE_OFF | ADC_IDLE_CONTINUE | ADC_FORMAT_INTG | ADC_CLK_MANUAL | ADC_AUTO_SAMPLING_OFF | ADC_SAMP_OFF)
#define ADC_CONFIG_ADCON2  (ADCON2_VAL | ADC_VREF_AVDD_AVSS | ADC_SCAN_OFF | ADC_INTR_CONV | ADC_ALT_BUF_OFF | ADC_ALT_INPUT_OFF)
#define ADC_CONFIG_ADCON3  (ADCON3_VAL | ADC_CONV_CLK_INTERNAL_RC | ADC_SAMPLE_TIME | ADC_CONV_CLK_Tcy)
#define ADC_CONFIG_ADCSSL  (ADCSSL_VAL | ADC_SCAN_AN)


/***********************************************************************/
/********************C O M P A R A T O R********************************/
/***********************************************************************/
/***********************************************************************/
/*Comparator register definition*/
 #define CMP_CMCON		    				 CM2CON
 #define CMP_CVRCON		    				 CVRCON

/*CMCON control register bit definition*/
#define CMP_Enable_Disable_Bit				CM2CONbits.CON
#define CMP_Output_Enable_Disable_Bit		CM2CONbits.COE
#define CMP_Output_Polarity_Bit				CM2CONbits.CPOL
#define CMP_Event_Bit						CM2CONbits.CEVT
#define CMP_CMCON_Ouput_Bit					CM2CONbits.COUT
#define CMP_Trigger_Select_HighBit			CM2CONbits.EVPOL1
#define CMP_Trigger_Select_LowBit			CM2CONbits.EVPOL0
#define CMP_Reference_Select_Bit			CM2CONbits.CREF
#define CMP_Channel_Select_HighBit			CM2CONbits.CCH1
#define CMP_Channel_Select_LowBit			CM2CONbits.CCH0
#define CMP_Trigger_Select_Bits				CM2CONbits.EVPOL
#define CMP_Channel_Select_Bits				CM2CONbits.CCH

/*CMSTAT register bit definition*/
#define CMP_Ouput_Bit						CMSTATbits.C2OUT

/*CMCON interrupt register bit definition*/

#define CMP_Interrupt_Flag_Bit				IFS1bits.CMIF
#define CMP_Interrupt_Enable_Bit			IEC1bits.CMIE
#define CMP_Interrupt_Priority_Bits			IPC4bits.CMIP

/******************************************************************************
 Macro      : CMP_EnblDsbl(state)
 Overview   : Macro Enables/Disables the Comparator
 Parameter  : state - *1 Comparator is enabled
                      *0 Comparator is disabled
 Remarks    : None
 *****************************************************************************/
#define CMP_EnblDsbl(state)      			(CMP_Enable_Disable_Bit = state)

/******************************************************************************
 Macro       : CMP_Output_EnblDsbl(state)
 Overview    : Macro Enables/Disables Comparator output on the output pad
 Parameter   : state -  *1 Comparator output driven on the output pad
                        *0 Comparator output is not driven on the output pad
 Remarks     : None
*****************************************************************************/
#define CMP_Output_EnblDsbl(state)    		(CMP_Output_Enable_Disable_Bit = state)

/******************************************************************************
 Macro       : CMP_Output_Polarity(state)
 Overview    :
 Parameter   : state -  *1
                        *0
 Remarks     : None
*****************************************************************************/
#define CMP_Output_Polarity(state)    		(CMP_Output_Polarity_Bit = state)


/******************************************************************************
 Macro       : CMP_Output_Polarity(state)
 Overview    :
 Parameter   : state -  *1
                        *0
 Remarks     : None
*****************************************************************************/
#define CMP_Event(state)    				(CMP_Event_Bit = state)


/******************************************************************************
 Macro       : CMP_Trigger_Select(state)
 Overview    :
 Parameter   : state -  *1
                        *0
 Remarks     : None
*****************************************************************************/
#define CMP_Trigger_Select(state)    		(CMP_Trigger_Select_Bits = state)


/******************************************************************************
 Macro       : CMP_Trigger_Select(state)
 Overview    :
 Parameter   : state -  *1
                        *0
 Remarks     : None
*****************************************************************************/
#define CMP_Reference_Select(state)    		(CMP_Reference_Select_Bit = state)


/******************************************************************************
 Macro       : CMP_Channel_Select(state) //n1:
 Overview    :
 Parameter   : state -  *1
                        *0
 Remarks     : None
*****************************************************************************/
#define CMP_Channel_Select(state)    		(CMP_Channel_Select_Bits = state)

/******************************************************************************
 Macro       : CMP_Get_STATE()
 Overview    : Macro Returns state of Comparator output
              When  C2INV = 0:
               1 = C2 VIN+ > C2 VIN-
               0 = C2 VIN+ < C2 VIN
              When   C2INV = 1:
               0 = C2 VIN+ > C2 VIN-
               1 = C2 VIN+ < C2 VIN-
 Parameter   : None
 Remarks     : State of Comparator depends on Inverse selection  bit in
              control register
 *****************************************************************************/
#define CMP_Get_STATE()      				(CMP_Ouput_Bit)

/***********************************************************************
Macro      : EnableIntCMP
Overview   : This macro enables the comparator interrupt.
Parameter  : None
Remarks    : This macro sets comparator Interrupt Enable bit of Interrupt
             Enable Control Register.
************************************************************************/
#define EnableIntCMP               			(CMP_Interrupt_Enable_Bit = 1)

/***********************************************************************
Macro      : DisableIntCMP
Overview   : This macro disables the comparator interrupt.
Parameter  : None
Remarks    : This macro clears comparator Interrupt Enable bit of Interrupt
             Enable Control register.
************************************************************************/
#define DisableIntCMP                		(CMP_Interrupt_Enable_Bit = 0)

/***********************************************************************
Macro      : SetPriorityIntCMP (priority)
Overview   : This macro sets priority for comparator interrupt.
Parameter  : priority - This input parameter is the level of interrupt priority
Remarks    : This macro sets comparator Interrupt Priority bits of Interrupt
             Priority Control register.
************************************************************************/
#define SetPriorityIntCMP(priority)     	(CMP_Interrupt_Priority_Bits = priority)

/*******************************************************************
Macro       : CMP_Clear_Intr_Status_Bit
Overview    : Macro to Clear Comparator Interrupt Status bit
Parameter   : None
Remarks     : None
*******************************************************************/
#define CMP_Clear_Intr_Status_Bit     		(CMP_Interrupt_Flag_Bit = 0)


/*CMxCON register definition*/
#define CMP_ENABLE                  	 0x8000 /* Comparator is enabled */
#define CMP_DISABLE                      0x0000 /* Comparator is disabled */
#define CMP_ENBL_DSBL_MASK               (~CMP_ENABLE)
#define CMP_OUTPUT_ENABLE                0x4000 /* Comparator output present on the CXOUT pin */
#define CMP_OUTPUT_DISABLE               0x0000 /* Comparator output is internal only */
#define CMP_OUTPUT_MASK                  (~CMP_OUTPUT_ENABLE)
#define CMP_OUTPUT_INVERT    	         0x2000 /* Comparator output inverted */
#define CMP_OUTPUT_NOT_INVERT            0x0000 /* Comparator output not inverted */
#define CMP_OUTPUT_INVERT_MASK           (~CMP_OUTPUT_INVERT)
#define CMP_CHANGE_STATE                 0x0200 /* Comparator output changed states */
#define CMP_NO_CHANGE                    0x0000 /* Comparator output did not change states */
#define CMP_STATE_MASK                   (~CMP_CHANGE_STATE )
#define CMP_INTERRUPT_ON_ANY_EDGE		 0X00C0 /* Comparator interrupt generated on any edge of the selected comparator output*/
#define CMP_INTERRUPT_ON_FALLING_EDGE	 0X0080 /* Comparator interrupt generated only on falling edge of the selected comparator output*/
#define CMP_INTERRUPT_ON_RISING_EDGE	 0X0040 /* Comparator interrupt generated only on rising edge of the selected comparator output*/
#define CMP_INTERRUPT_DISABLED			 0X0000  /* Comparator interrupt generation is disabled */
#define CMP_INTERRUP_EDGE_MASK           (~CMP_INTERRUPT_ON_ANY_EDGE)
#define CMP_POS_IP_CV_Ref                0x0010 /* Input is connected to internal CVref voltage */
#define CMP_POS_IP_CXINA 	             0x0000 /* Input is connected to CXINA pin */
#define CMP_POS_IP_MASK                  (~CMP_POS_IP_CV_Ref)
#define CMP_NEG_IP_CXINB				 0X0000 /* Input is connected to CXINB pin */
#define CMP_NEG_IP_CXINC			     0X0001 /* Input is connected to CXINC pin */
#define CMP_NEG_IP_CXIND			     0X0002 /* Input is connected to CXIND pin */

/*CVRCON register definition*/
#define CMP_VRef_Enable                  0x0080 /* CVREF circuit powered on */
#define CMP_VRef_Disable                 0x0000 /* CVREF circuit powered down */
#define CMP_VRef_MASK                    (~CMP_VRef_Enable)
#define CMP_VRef_OUTPUT_Enable           0x0040 /* CVREF voltage level is output on CVREF pin */
#define CMP_VRef_OUTPUT_Disable          0x0000 /* CVREF voltage level is disconnected from CVREF pin */
#define CMP_VRef_OUTPUT_MASK             (~CMP_VRef_OUTPUT_Enable)
#define CMP_VRef_SELECT_24_STEPS   	 	 0x0020 /* 0 to 0.67 CVRSRC, with CVRSRC/24 step size */
#define CMP_VRef_SELECT_32_STEPS         0x0000 /* 0.25 CVRSRC to 0.75 CVRSRC, with CVRSRC/32 step size */
#define CMP_VRef_STEP_SELECT_MASK        (~CMP_VRef_SELECT_24_STEPS)
#define CMP_Vrsrc_Vref_Vref        		 0x0010 /* Comparator reference source CVRSRC = VREF+ – VREF- */
#define CMP_Vrsrc_AVDD_AVSS        		 0x0000 /* Comparator reference source CVRSRC = AVDD – AVSS */
#define CMP_Vrsrc_MASK                   (~CMP_Vrsrc_Vref_Vref)
#define CMP_CVrsrc      				 0x000F /* 0 CVRSRC with CVRSRC/24 step size, 0.25 CVRSRC with CVRSRC/32 step size */

/*Registers Defaults*/
#define CMP_CMCON_VAL    				 0x0000
#define CVREF_VAL    				 	 0x0000


#define CMP_CONFIG_CMCON 				(CMP_CMCON_VAL | CMP_ENABLE | CMP_OUTPUT_DISABLE | CMP_OUTPUT_NOT_INVERT  \
										| CMP_NO_CHANGE | CMP_INTERRUPT_DISABLED | CMP_POS_IP_CV_Ref | CMP_NEG_IP_CXINB)

#define CMP_CONFIG_CVRCON				(CVREF_VAL | CMP_VRef_Enable | CMP_VRef_OUTPUT_Enable | CMP_VRef_SELECT_32_STEPS \
										| CMP_Vrsrc_AVDD_AVSS | CMP_CVrsrc)



/***********************************************************************/
/********************C T M U********************************************/
/***********************************************************************/
/************************************************************************/

 /*CTMUCON Control Register*/
#if defined CTMU_v1 || defined CTMU_v2

 /*CTMUCON Control Register*/
 #define CTMU_ENABLE       			   0x8000 /*CTMU is Enabled*/
 #define CTMU_DISABLE      			   0x0000 /*CTMU is Disabled*/
 #define CTMU_ENBL_DISBL_MASK          (~CTMU_ENABLE)

 #define CTMU_IDLE_STOP                0x2000 /*CTMU discontinue module operation in Idle mode*/
 #define CTMU_IDLE_CONTINUE            0x0000 /*CTMU Operate in Idle mode*/
 #define CTMU_IDLE_MASK                (~CTMU_IDLE_STOP)

 #define CTMU_TIME_GEN_ENABLE          0x1000 /*CTMU enables edge delay generation*/
 #define CTMU_TIME_GEN_DISABLE         0x0000 /*CTMU disables edge delay generation*/
 #define CTMU_TIME_GEN_MASK            (~CTMU_TIME_GEN_ENABLE)

 #define CTMU_EDGE_ENABLE              0x0800 /*CTMU edges are not blocked*/
 #define CTMU_EDGE_DISABLE             0x0000 /*CTMU edges are blocked*/
 #define CTMU_EDGE_MASK                (~CTMU_EDGE_ENABLE)

 #define CTMU_EDGE_SEQUENCE_ON         0x0400 /*Edge1 event must occur before edge2 event can occur*/
 #define CTMU_EDGE_SEQUENCE_OFF        0x0000 /*No edge sequence os needed*/
 #define CTMU_EDGE_SEQUENCE_MASK       (~CTMU_EDGE_SEQUENCE)

 #define CTMU_ANA_CURR_SOURCE_GND      0x0200 /*CTMU Analog current source output is grounded*/
 #define CTMU_ANA_CURR_SOURCE_NOT_GND  0x0000 /*CTMU Analog current source output is not grounded*/
 #define CTMU_ANA_CURR_SOURCE_MASK     (~CTMU_ANA_CURR_SOURCE_GND)

 #define CTMU_TRIG_OUTPUT_ENABLE       0x0100 /*Trigger output is enabled*/
 #define CTMU_TRIG_OUTPUT_DISABLE      0x0000 /*Trigger output is disabled*/
 #define CTMU_TRIG_OUTPUT_MASK         (~CTMU_TRIG_OUTPUT)

 #if defined CTMU_v1
 /*CTMUCON Control Register*/
 #define CTMU_EDGE1_POLARITY_POS       0x0010 /*Edge 1 programmed for a positive edge response*/
 #define CTMU_EDGE1_POLARITY_NEG       0x0000 /*Edge 1 programmed for a negative edge response*/
 #define CTMU_EDGE1_POLARITY_MASK      (~CTMU_EDGE2_POS_POLARITY)

 #define CTMU_EDGE1_SOURCE_CTED1       0x000C /*CTED1 is a source select for Edge1*/
 #define CTMU_EDGE1_SOURCE_CTED2       0x0008 /*CTED2 is a source select for Edge1*/
 #define CTMU_EDGE1_SOURCE_OC1         0x0004 /*OC1 is a source select for Edge1*/
 #define CTMU_EDGE1_SOURCE_TIMER1      0x0000 /*TIMER1 is a source select for Edge1*/
 #define CTMU_EDGE1_SOURCE_MASK        (~CTMU_EDGE2_SOURCE_CTED1)

 #define CTMU_EDGE2_POLARITY_POS       0x0080 /*Edge 2 programmed for a positive edge response*/
 #define CTMU_EDGE2_POLARITY_NEG       0x0000 /*Edge 2 programmed for a negative edge response*/
 #define CTMU_EDGE2_POLARITY_MASK      (~CTMU_EDGE2_POS_POLARITY)

 #define CTMU_EDGE2_SOURCE_CTED1       0x0060 /*CTED1 is a source select for Edge2*/
 #define CTMU_EDGE2_SOURCE_CTED2       0x0040 /*CTED2 is a source select for Edge2*/
 #define CTMU_EDGE2_SOURCE_OC1         0x0020 /*OC1 is a source select for Edge2*/
 #define CTMU_EDGE2_SOURCE_TIMER1      0x0000 /*TIMER1 is a source select for Edge2*/
 #define CTMU_EDGE2_SOURCE_MASK        (~CTMU_EDGE2_SOURCE_CTED1)

  #else
  /*CTMUCON2 Control Register*/
 #define CTMU_EDGE1_EDGE_SENSITIVE     0x8000 /*Input is edge-sensitive*/
 #define CTMU_EDGE1_LEVEL_SENSITIVE    0x0000 /*Input is level-sensitive*/
 #define CTMU_EDGE1_SENSITIVE_MASK     (~0x8000)

 #define CTMU_EDGE1_POLARITY_POS       0x4000 /*Edge 1 programmed for a positive edge response*/
 #define CTMU_EDGE1_POLARITY_NEG       0x0000 /*Edge 1 programmed for a negative edge response*/
 #define CTMU_EDGE1_POLARITY_MASK      (~CTMU_EDGE2_POS_POLARITY)

 #define CTMU_EDGE1_SOURCE_CMP3        0x3C00 /*Edge1 source is Comparator 3 Output*/
 #define CTMU_EDGE1_SOURCE_CMP2        0x3800 /*Edge1 source is Comparator 2 Output*/
 #define CTMU_EDGE1_SOURCE_CMP1        0x3400 /*Edge1 source is Comparator 1 Output*/
 #define CTMU_EDGE1_SOURCE_IC3         0x3000 /*Edge1 source is Input Capture 3*/
 #define CTMU_EDGE1_SOURCE_IC2         0x2C00 /*Edge1 source is Input Capture 2*/
 #define CTMU_EDGE1_SOURCE_IC1         0x2800 /*Edge1 source is Input Capture 1*/
 #define CTMU_EDGE1_SOURCE_CTED8       0x2400 /*Edge1 source is CTED8*/
 #define CTMU_EDGE1_SOURCE_CTED1       0x0C00 /*Edge1 source is CTED1*/
 #define CTMU_EDGE1_SOURCE_CTED2       0x0800 /*Edge1 source is CTED2*/
 #define CTMU_EDGE1_SOURCE_OC1         0x0400 /*Edge1 source is OC1*/
 #define CTMU_EDGE1_SOURCE_TIMER1      0x0000 /*Edge1 source is Timer1*/
 #define CTMU_EDGE1_SOURCE_MASK        (~0x3C00)

 #define CTMU_EDGE2_EDGE_SENSITIVE     0x0080 /*Input is edge-sensitive*/
 #define CTMU_EDGE2_LEVEL_SENSITIVE    0x0000 /*Input is level-sensitive*/
 #define CTMU_EDGE2_SENSITIVE_MASK     (~0x0080)

 #define CTMU_EDGE2_POLARITY_POS       0x0040 /*Edge 2 programmed for a positive edge response*/
 #define CTMU_EDGE2_POLARITY_NEG       0x0000 /*Edge 2 programmed for a negative edge response*/
 #define CTMU_EDGE2_POLARITY_MASK      (~0x0040)

 #define CTMU_EDGE2_SOURCE_CMP3        0x003C /*Edge2 source is Comparator 3 Output*/
 #define CTMU_EDGE2_SOURCE_CMP2        0x0038 /*Edge2 source is Comparator 2 Output*/
 #define CTMU_EDGE2_SOURCE_CMP1        0x0034 /*Edge2 source is Comparator 1 Output*/
 #define CTMU_EDGE2_SOURCE_IC3         0x002C /*Edge2 source is Input Capture 3*/
 #define CTMU_EDGE2_SOURCE_IC2         0x0028 /*Edge2 source is Input Capture 2*/
 #define CTMU_EDGE2_SOURCE_IC1         0x0024 /*Edge2 source is Input Capture 1*/
 #define CTMU_EDGE2_SOURCE_CTED10      0x0014 /*Edge2 source is CTED10*/
 #define CTMU_EDGE2_SOURCE_CTED9       0x0010 /*Edge2 source is CTED9*/
 #define CTMU_EDGE2_SOURCE_CTED1       0x00C0 /*Edge2 source is CTED1*/
 #define CTMU_EDGE2_SOURCE_CTED2       0x0080 /*Edge2 source is CTED2*/
 #define CTMU_EDGE2_SOURCE_OC1         0x0040 /*Edge2 source is OC1*/
 #define CTMU_EDGE2_SOURCE_TIMER1      0x0000 /*Edge2 source is Timer1*/
 #define CTMU_EDGE2_SOURCE_MASK        (~0x003C)
 #endif

 /*CTMU1CON Current Control register*/
 #define CTMU_POS_CURR_TRIM		       0x0400 /*2% of Positive change from nominal current*/
 #define CTMU_NEG_CURR_TRIM            0xFC00 /*2% of Negative change from nominal current*/
 #define CTMU_NOMINAL_CURRENT          0x0000 /*Nominal Current output specified by IRNG1:IRNG0*/

 #define CTMU_INT_PRI                	0x0000 /*CTMU interrupt priority is 0*/

 #define CTMU_INT_ENABLE               0x0008 /* Enable CTMU interrupts */
 #define CTMU_INT_DISABLE              0x0000 /* Disable CTMU interrupts */

#if defined CTMU_v1
/************************************************************************
Macro       : Set_CTMU_ENABLE_Status
Overview    : setting or clearing CTMU Enable Module Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Set_CTMU_ENABLE_Status(State)   		(CTMUCONbits.CTMUEN = State)

/************************************************************************
Macro       : Idle_Mode_CTMU_Operation
Overview    : CTMU Operation in Idle
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Idle_Mode_CTMU_Operation(State)   		(CTMUCONbits.CTMUSIDL = State)

/************************************************************************
Macro       : Set_CTMU_Time_Generation
Overview    : setting or clearing CTMU TIME Generation Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Set_CTMU_Time_Generation(State)   		(CTMUCONbits.TGEN = State)


/************************************************************************
Macro       : Enable_Disable_CTMU_Time_Generation
Overview    : setting or clearing CTMU TIME Generation Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Block_CTMU_Edge(State)   				(CTMUCONbits.EDGEN = 0)

/************************************************************************
Macro       : Enable_Disable_CTMU_Time_Generation
Overview    : setting or clearing CTMU TIME Generation Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Unblock_CTMU_Edge(State)   				(CTMUCONbits.EDGEN = 1)


/************************************************************************
Macro       : Set_CTMU_Edge_Sequence
Overview    : setting or clearing CTMU Edge Sequence Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Set_Edge_Sequence(State)   				(CTMUCONbits.EDGSEQEN = State)


/************************************************************************
Macro       : Enable_CTMU_CurrentDischarge
Overview    : setting the CTMU Current Discharge  Bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMU_CurrentDischarge   			(CTMUCONbits.IDISSEN = 1)

/************************************************************************
Macro       : Disable_CTMU_CurrentDischarge
Overview    : Clearing the CTMU Current Discharge  Bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Disble_CTMU_CurrentDischarge   			(CTMUCONbits.IDISSEN = 0)



/************************************************************************
Macro       : Set_CTMU_Trigger_Control
Overview    : setting or clearing CTMU Trigger Control Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Set_CTMU_Trigger_Control(State)   		(CTMUCONbits.CTTRIG = State)



/************************************************************************
Macro       : Enble_CTMU_Positive_Edge2_Polarity
Overview    : By setting Edge 2 Polarity Select bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMU_Positive_Edge2_Polarity		(CTMUCONbits.EDG2POL = 1)


/************************************************************************
Macro       : Enble_CTMU_Negative_Edge2_Polarity
Overview    : By setting Edge 2 Polarity Select bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMU_Negative_Edge2_Polarity		(CTMUCONbits.EDG2POL = 0)


/************************************************************************
Macro       : Enble_CTMU_Positive_Edge1_Polarity
Overview    : By setting Edge 1 Polarity Select bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMU_Positive_Edge1_Polarity		(CTMUCONbits.EDG1POL = 1)


/************************************************************************
Macro       : Enble_CTMU_Negative_Edge1_Polarity
Overview    : By setting Edge 1 Polarity Select bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMU_Negative_Edge1_Polarity		(CTMUCONbits.EDG1POL = 0)


/************************************************************************
Macro       : CTMU_Edge1_Source_Select
Overview    : Edge 1 Source Select bits
Parameters  :  State
Remarks     : None.
**************************************************************************/
#define CTMU_Edge1_Source_Select(State)   		(CTMUCONbits.EDG1SEL = State)


/************************************************************************
Macro       : CTMU_Edge2_Source_Select
Overview    : Edge 2 Source Select bits
Parameters  :  TRIGGER_SOURCE_TIMER1=0,
			TRIGGER_SOURCE_OC,
			TRIGGER_SOURCE_EXTERNAL2,
			TRIGGER_SOURCE_EXTERNAL1
Remarks     : None.
**************************************************************************/
#define CTMU_Edge2_Source_Select(State)   		(CTMUCONbits.EDG2SEL = State)


/************************************************************************
Macro       : Enble_CTMUEdge1
Overview    : By setting edge1 status bit current source enables
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMUEdge1  						(CTMUCONbits.EDG1STAT = 1)


/************************************************************************
Macro       : Enble_CTMUEdge2
Overview    : By setting edge2 status bit current source enables
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMUEdge2 						(CTMUCONbits.EDG2STAT = 1)


/************************************************************************
Macro        :Disbl_CTMUEdge1
Overview    : By clearing edge1 status bit disable the current source
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Disbl_CTMUEdge1 						(CTMUCONbits.EDG1STAT = 0)


/************************************************************************
Macro       :Disbl_CTMUEdge2
Overview    : By clearing edge2 status bit disable the current source
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Disbl_CTMUEdge2							(CTMUCONbits.EDG2STAT = 0)


/************************************************************************
Macro       : Disbl_Currentsource
Overview    : By clearing EDGSTAT bit disable the source.
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Disbl_CurrentSource   					( CTMUCONbits.EDG1STAT = 0 , CTMUCONbits.EDG2STAT = 0 )


/************************************************************************
Macro       : Enabl_Currentsource
Overview    : By setting EDGSTAT bit disable the source.
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CurrentSource   					(CTMUCONbits.EDG1STAT = 1 , CTMUCONbits.EDG2STAT = 1 )


/************************************************************************
Macro       : CTMUEdge1_Status
Overview    : Returns the status of CTMU edge1
Parameters  : None
Remarks     : None.
**************************************************************************/
#define CTMUEdge1_Status      					CTMUCONbits.EDG1STAT

/************************************************************************
Macro       : CTMUEdge2_Status
Overview    : Returns the status of CTMU edge2
Parameters  : None
Remarks     : None.
**************************************************************************/
#define CTMUEdge2_Status  	 					CTMUCONbits.EDG2STAT


#elif defined CTMU_v2
/************************************************************************
Macro       : Set_CTMU_ENABLE_Status
Overview    : setting or clearing CTMU Enable Module Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Set_CTMU_ENABLE_Status(State)   		(CTMUCON1bits.CTMUEN = State)

/************************************************************************
Macro       : Idle_Mode_CTMU_Operation
Overview    : CTMU Operation in Idle
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Idle_Mode_CTMU_Operation(State)   		(CTMUCON1bits.CTMUSIDL = State)

/************************************************************************
Macro       : Set_CTMU_Time_Generation
Overview    : setting or clearing CTMU TIME Generation Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Set_CTMU_Time_Generation(State)   		(CTMUCON1bits.TGEN = State)


/************************************************************************
Macro       : Enable_Disable_CTMU_Time_Generation
Overview    : setting or clearing CTMU TIME Generation Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Block_CTMU_Edge(State)   				(CTMUCON1bits.EDGEN = 0)

/************************************************************************
Macro       : Enable_Disable_CTMU_Time_Generation
Overview    : setting or clearing CTMU TIME Generation Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Unblock_CTMU_Edge(State)   				(CTMUCON1bits.EDGEN = 1)


/************************************************************************
Macro       : Set_CTMU_Edge_Sequence
Overview    : setting or clearing CTMU Edge Sequence Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Set_Edge_Sequence(State)   				(CTMUCON1bits.EDGSEQEN = State)


/************************************************************************
Macro       : Enable_CTMU_CurrentDischarge
Overview    : setting the CTMU Current Discharge  Bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMU_CurrentDischarge   			(CTMUCON1bits.IDISSEN = 1)

/************************************************************************
Macro       : Disable_CTMU_CurrentDischarge
Overview    : Clearing the CTMU Current Discharge  Bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Disble_CTMU_CurrentDischarge   			(CTMUCON1bits.IDISSEN = 0)


/************************************************************************
Macro       : Set_CTMU_Trigger_Control
Overview    : setting or clearing CTMU Trigger Control Bit
Parameters  : ENABLE '1' or DISABLE '0'
Remarks     : None.
**************************************************************************/
#define Set_CTMU_Trigger_Control(State)   		(CTMUCON1bits.CTTRIG = State)


/************************************************************************
Macro       : Enble_CTMU_Positive_Edge2_Polarity
Overview    : By setting Edge 2 Polarity Select bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMU_Positive_Edge2_Polarity		(CTMUCON2bits.EDG2POL = 1)


/************************************************************************
Macro       : Enble_CTMU_Negative_Edge2_Polarity
Overview    : By setting Edge 2 Polarity Select bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMU_Negative_Edge2_Polarity		(CTMUCON2bits.EDG2POL = 0)


/************************************************************************
Macro       : Enble_CTMU_Positive_Edge1_Polarity
Overview    : By setting Edge 1 Polarity Select bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMU_Positive_Edge1_Polarity		(CTMUCON2bits.EDG1POL = 1)


/************************************************************************
Macro       : Enble_CTMU_Negative_Edge1_Polarity
Overview    : By setting Edge 1 Polarity Select bit
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMU_Negative_Edge1_Polarity		(CTMUCON2bits.EDG1POL = 0)


/************************************************************************
Macro       : CTMU_Edge1_Source_Select
Overview    : Edge 1 Source Select bits
Parameters  :  State
Remarks     : None.
**************************************************************************/
#define CTMU_Edge1_Source_Select(State)   		(CTMUCON2bits.EDG1SEL = State)


/************************************************************************
Macro       : CTMU_Edge2_Source_Select
Overview    : Edge 2 Source Select bits
Parameters  :  TRIGGER_SOURCE_TIMER1=0,
			TRIGGER_SOURCE_OC,
			TRIGGER_SOURCE_EXTERNAL2,
			TRIGGER_SOURCE_EXTERNAL1
Remarks     : None.
**************************************************************************/
#define CTMU_Edge2_Source_Select(State)   		(CTMUCON2bits.EDG2SEL = State)


/************************************************************************
Macro       : Enble_CTMUEdge1
Overview    : By setting edge1 status bit current source enables
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMUEdge1  						(CTMUCON2bits.EDG1 = 1)


/************************************************************************
Macro       : Enble_CTMUEdge2
Overview    : By setting edge2 status bit current source enables
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CTMUEdge2 						(CTMUCON2bits.EDG2 = 1)


/************************************************************************
Macro        :Disbl_CTMUEdge1
Overview    : By clearing edge1 status bit disable the current source
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Disbl_CTMUEdge1 						(CTMUCON2bits.EDG1 = 0)


/************************************************************************
Macro       :Disbl_CTMUEdge2
Overview    : By clearing edge2 status bit disable the current source
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Disbl_CTMUEdge2							(CTMUCON2bits.EDG2 = 0)


/************************************************************************
Macro       : Disbl_Currentsource
Overview    : By clearing EDGSTAT bit disable the source.
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Disbl_CurrentSource   					( CTMUCON2bits.EDG1 = 0 , CTMUCON2bits.EDG2 = 0 )


/************************************************************************
Macro       : Enabl_Currentsource
Overview    : By setting EDGSTAT bit disable the source.
Parameters  : None
Remarks     : None.
**************************************************************************/
#define Enble_CurrentSource   					(CTMUCON2bits.EDG1 = 1 , CTMUCON2bits.EDG2 = 1 )


/************************************************************************
Macro       : CTMUEdge1_Status
Overview    : Returns the status of CTMU edge1
Parameters  : None
Remarks     : None.
**************************************************************************/
#define CTMUEdge1_Status      					CTMUCON2bits.EDG1

/************************************************************************
Macro       : CTMUEdge2_Status
Overview    : Returns the status of CTMU edge2
Parameters  : None
Remarks     : None.
**************************************************************************/
#define CTMUEdge2_Status  	 					CTMUCON2bits.EDG2
#endif


/************************************************************************
Macro       : CTMU_Trim_Value
Overview    : Sets the Trim Value for CTMU
Parameters  : Singed data Range (011111) i.e +31 to (100001) i.e -1
Remarks     : None.
**************************************************************************/
#define CTMU_Trim_Value(Value)	 				CTMUICONbits.ITRIM = (Value)


/************************************************************************
Macro          : CTMU_Select_Current_Source
Overview       : Sets the current source range Value for CTMU
Parameters     : CURRENT_RANGE_100XBASE_CURRENT //urrent source Range is 100*Base current (55uA)
 *				 CURRENT_RANGE_10XBASE_CURRENT  //Current source Range is 10*Base current (5.5uA)
 *				 CURRENT_RANGE_BASE_CURRENT     //Current source Range is Base current (0.55uA)
 *				 CURRENT_SRC_DISABLED      		//Current source disabled
 *
Remarks      : None.
**************************************************************************/
#define CTMU_Select_Current_Source(Value)	 	CTMUICONbits.IRNG = (Value)


/************************************************************************
Macro          : CTMU_Get_Current_Source
Overview     : Gets the Current Source range value
Parameters  : None
Remarks      : None.
**************************************************************************/
#define CTMU_Get_Current_Source	 				CTMUICONbits.IRNG


/***********************************************************************
Macro      : EnableIntCTMU
Overview   : This macro enables the CTMU interrupt.
Parameters : None
Remarks    : This macro sets CTMU Interrupt Enable bit of Interrupt
                  Enable Control Register.
************************************************************************/
#define EnableIntCTMU                			(IEC4bits.CTMUIE = 1)

/***********************************************************************
Macro      : DisableIntCTMU
Overview   : This macro disables the CTMU interrupt.
Parameters : None
Remarks    : This macro clears CTMU Interrupt Enable bit of Interrupt
             Enable Control register.
************************************************************************/
#define DisableIntCTMU               			(IEC4bits.CTMUIE = 0)

/***********************************************************************
Macro      : SetPriorityIntCTMU(priority)
Overview   : This macro sets priority for CTMU interrupt.
Parameters : priority - This input parameter is the level of interrupt priority
Remarks    : This macro sets CTMU Interrupt Priority bits of Interrupt
             Priority Control register.
************************************************************************/
#define SetPriorityIntCTMU(priority)    		(IPC19bits.CTMUIP = priority)

/*******************************************************************
Macro       : CTMU_Clear_Intr_Status_Bit
Overview    : Macro to Clear CTMU Interrupt Status bit
Parameters  : None
Remarks     : None
*******************************************************************/
#define CTMU_Clear_Intr_Status_Bit    			(IFS4bits.CTMUIF = 0)

#endif //#ifdef CTMU_v1 || defined CTMU_v2

#endif //#ifdef __PIC24F__

#endif	// _MTOUCH_PIC24_CTMU_PHYSICAL_H
